BRCS01C
AC/DC Residual Current Sensor (IEC Version)
The BRCS01C is an AC/DC residual current sensor with two separate fault signal outputs – one Pin for type-A 30mA + DC 6mA residual current detection (RDC-PD application) and the other Pin for DC 6mA residual current detection (RDC-MD application). It can be used for built-in residual current protection at AC charging system.
5V DC or 12V DC interfaces available to meet different design practices
Two fault signal pins for solely DC 6mA and Type-A 30mA +DC 6mA alarming
Cost-effective solution of built-in residual current device for AC EV charger
Fast response time facilitating a broad selection of switching devices
Compact design with 17mm through-hole for charging cable up to 3P+N 32A
